Elevate Your HPLC Performance with the Biovanix Dual Wavelength UV/VIS Detector

Achieve Unprecedented Precision and Stability in Liquid Phase Purification

For high-performance liquid chromatography (HPLC) purification systems, the quality of your detector is paramount to the integrity and reliability of your results. The Biovanix Dual Wavelength UV/VIS Detector is engineered to meet the stringent demands of modern separation science, offering a fully digitized platform that sets a new standard for baseline stability and data accuracy.

UV Detector Parameter

النوع	PUD0010	PUD0100 / PUD0200	PUD0500 / PUD1000	PUD3000
Flow Cell	Analysis flow cell, SST or PEEK 10mm optical range	Preparative flow cells, variable optical range in SST or PEEK
Connector	1/16	1/16 / 1/8	1/8	6 مم
Wavelength Range & Light Source	190-400nm deuterium lamp, 400-700nm tungsten lamp
Bandwidth	8nm
Wavelength الدقة	±0.75nm		±1nm
Wavelength Repeatability	0.2nm	0.3nm
Baseline Noise (Static)	1*10-5 AU
Baseline Drift (Static)	1*10-4 AU/h	1*10-4 AU/h	1*10-4 AU/h	1*10-4 AU/h
Detection Range	（0~5）AU
Min detection limit	≤4*10^-9g/mL	≤4*10^-8g/mL	≤4*10^-7g/mL	≤4*10^-5g/mL
Control Mode	RS232 أو LAN
العرض	5.0-inch touch screen
Size	368260140(LWH)
Wattage	75W
الوزن	6.9 كجم

Optical Fiber Detector & Optical Fiber Flow Cell

Optical fiber detector: 190 – 700 nm, variable dual wavelength UV/VIS detector with fiber optic.

	Optical Fiber Detector	Optical Fiber Flow Cells
PUD0010	190 – 700 nm optical fiber detector	10 mm path length, 1/16″, 10 µl volume stainless steel
PUD0050	190 – 700 nm optical fiber detector	3 mm path length, 1/16″, 2 µl volume
PUD0100	190 – 700 nm optical fiber detector	3 mm path length, 1/16″, 2 µl volume
PUD0200	190 – 700 nm optical fiber detector	3 mm path length, 1/16″, 2 µl volume
PUD0500	190 – 700 nm optical fiber detector	3 mm path length, 1/8″, 1.9 µl volume
PUD1000	190 – 700 nm optical fiber detector	3 mm path length, 1/8″, 1.9 µl volume
PUD3000	190 – 700 nm optical fiber detector	2 mm path length, 1/16″, 6.28 µl volume

Key Value Proposition: Digitize Your Data, Eliminate the Noise

Traditional detectors introduce noise and drift through analog data acquisition. The Biovanix detector fundamentally transforms this by integrating a built-in digital signal processing and control system.

Noise Reduction: Data is digitized directly at the source, reducing baseline noise and drift to a new limit.
Simplified Integration: The digital output function allows for direct connection to a computer via a serial port, completely eliminating the need for an external data acquisition unit (DAU). This saves bench space, reduces complexity, and ensures signal fidelity.

Core Features Designed for Reliability and Accuracy

Biovanix advanced design ensures optimal performance across all your purification protocols.

Feature	Technical Benefit	User Advantage
Integrated Digital Control	Built-in DSP and control system	Reduced Setup Time and pristine data quality.
High-Performance Lamp	Deuterium lamp with stable signal and high energy output	Consistent and sensitive detection across various wavelengths.
Flow Cell Flexibility	Flow cell units selectable for different flow rates and sizes	Direct Flow Detection without diverting the sample, preserving resolution and minimizing hold-up volume.
Advanced System Control	Latest ARM system program control	Higher accuracy and reproducible separation results.
Integrated Power Supply	Stable and self-contained power management	Enhanced Stability and suitable for use in explosion-proof environments.

Seamless Integration and Operational Excellence

The Biovanix detector is designed for operators who demand both high performance and ease of use.

Direct Detection, Maximum Efficiency

The system supports different flow cell units tailored to specific flow rates. This crucial design allows you to detect the flow directly without the need for flow splitting or diverting the stream. This direct path maintains the highest possible concentration, ensuring maximum sensitivity and quantitative accuracy.

Stability You Can Trust

The detector features an integrated power supply, which ensures power stability far superior to external units. This is critical for maintaining baseline performance, especially in long-run purification protocols or challenging industrial settings, making it suitable for explosion-proof applications.

المنتجات

UV Detector

UV Detector with Optical Fiber

Optimize Your Results: Applications

Biovanix Dual Wavelength UV/VIS Detector is the ideal choice for demanding applications in:

Pharmaceutical Development: Quality control and purification of Active Pharmaceutical Ingredients (APIs).
Biotechnology: Separation and monitoring of proteins, peptides, and nucleic acids.
Chemical Synthesis: Monitoring reaction progress and purification of complex organic molecules.
